TS8 series illuminated tact switch.pdf
Illuminated Through-hole Mounting Tact Switches With Two LEDs
The vertical illuminated tact switch have a inserted LED into the 6*6 light tactile switch,the led is not related to if the button is pressed or not .The Cathode of the LED was usually marked with a red, but please do check the polarity before welding it or design PCB.the 6x6mm LED tact switch provides a variety of LED colors option,such as red,green,white,yellow,blue and orange six single LED colors as well as bi-color LEDs.
Model:TS8-0000W
Rated:12VDC 50mA
Switch Size:6*6*7mm
Product Name:Tactile Switch
Function: Momentary
LED Color:Red/Blue/Green/White/Orange/Yellow/Bi-color
Cap Options: Circle and Square
Our clients located in North America ,Europe and Asia,they are all making the audio-visual equipment,security equipment,industry devices and medical product,tele-communications filed.
