Illuminated Metal Push Button Switch MS22

The 22mm metal push button switch with dot light  for compact power and control panels.

Product Introduction

This 22mm metal push button switch is designed for equipment panels where the button needs to provide both physical control and a clear status indication. Unlike a large illuminated ring, the LED is positioned as a single dot in the center of the flat button. This gives the panel a more restrained appearance and helps keep the light from spreading into adjacent buttons.

Product Views

Product Features and Selling Points

1. Center Dot Light Instead of a Large Ring

The most noticeable feature is the center dot LED. For panels with several buttons installed side by side, a dot light provides a more focused indication than a full illuminated ring.

This can help reduce unwanted light overlap between adjacent buttons. It is a practical option for equipment manufacturers who need status feedback but do not need the button to be highly visible from a distance.

2. Flat Head for a Simple Panel Appearance

The flat button surface sits neatly with the surrounding panel and gives the equipment a straightforward industrial appearance. It is suitable for control panels designed with a clean and compact layout.

The button can also be easier to wipe during routine equipment maintenance compared with designs with deep recesses or complicated surfaces.

3. Latching Function for On/Off Control

The latching mechanism is suitable for applications where the switching state needs to remain after the button is released.

This makes the switch useful for power activation, equipment start/stop, mode selection, and other maintained control functions, depending on the electrical circuit.

4. 304 Stainless Steel Housing

The 304 stainless steel housing gives the switch a firm metal construction and good resistance to everyday wear and corrosion.

This is particularly useful for equipment that is frequently operated, cleaned, or exposed to oil, dust, humidity, and occasional splashing. It also provides a consistent metal appearance for industrial equipment panels.

5. IP67 Protection

The IP67 version is designed for applications where dust and water protection are important. It can be considered for control panels in energy storage, photovoltaic, power distribution, and outdoor electrical equipment.

6. Multiple Contact and LED Options

Depending on the model, contact configurations can include 1NO, 1NC, and 1NO+1NC. Common LED voltage options include 6V, 12V, and 24V DC, with different LED colors available for product selection.

Applications

This switch is particularly suitable for new energy and power equipment, including:

Energy storage cabinets, Solar PV inverters, UPS systems, AC/DC distribution boxes, Battery testing equipment, Power control panels, Industrial automation equipment, Electrical control cabinets

Why FVWIN?

FVWIN manufactures electronic switches and connectors for industrial, commercial, and electronic equipment. Our product range includes metal push button switches, illuminated tact switches, DIP switches, DC power jacks, and other control and connection components.

For metal push button projects, FVWIN can provide different mounting sizes, head styles, switching functions, LED configurations, contact arrangements, and wiring options. OEM and ODM requirements can also be discussed according to the customer's equipment design.

FAQ

Q1: What makes this 22mm metal push button different from a ring LED button?
A: This model uses a center dot LED rather than a full illuminated ring. The light is more concentrated and can help reduce visual interference when multiple buttons are installed close together.

Q2: Is the switch momentary or latching?
A: This model uses a latching function. The switching state remains after pressing until the button is operated again.

Q3: What material is the housing?
A: The housing is made from 304 stainless steel.
