ILLUMINATED TACT SWITCH
Through Hole LED Tact Switches With Clear Cap
TS8 series illuminated tact switch.pdf
Through Hole LED Tact Switches With Clear Button
This is 6mm illuminated tact switch with through hole led indicator ,and it matched with diameter 5.5* height 10.4mm cylindrical cap,the bottom of cap size is 7.5*7.5*2.4mm;the TS8-00TWX led tact switches is widely used for electronic instruments,such as synthesizers,we have multiple clients uses it on the front panel control button of synthesizer.
Brand:FVWIN
Model:TS8-00TWU
Rating: DC 12V 50mA
Total Travel: 0.25+/-0.1mm
Terminal: SMD,Through-in
Tactile Switch Size:6*6*7mm
LED Color:Red/Blue/Green/White/Orange/Bi-color
l Incoming material inspection,all is ok,then put them into production
l Incoming mas production to plastic injection and hardware punching
l Assemble the parts together
l Inspecting the function of finished products.
Q:What's application for TS8-00TAX illuminated tact switches?
A:it's widely suitable for electronic instruments,such as synthesizer,modular synth
Q:Can make the white cap to transparent ?
A:Sure
Q:Can you make it with SMT type?
A:yes,but it only soldering by manual.
