2 Way SMT DIP Switch

View PDF materials

2 Position, Surface Mount, 2.54 mm Pitch, Flat Slide Actuator, Flat Bottom, SMT Pin, DIP Switch.

A 2-Way SMT DIP switch is a surface-mount technology (SMT) component designed for printed circuit board (PCB) mounting. The "2-Way" designation typically indicates that the switch has two positions or settings.

1. Number of Positions:

A 2-Way DIP switch has two positions, meaning it can be toggled between two states.

2. Surface-Mount Technology (SMT):

SMT DIP switches are designed for surface mounting directly onto the PCB. This is in contrast to through-hole DIP switches that have pins inserted through holes in the PCB.
