10 Pole 2.54mm Pitch DIP Switch

A 10-Pole 2.54mm Pitch DIP Switch is a specific type of DIP (Dual In-line Package) switch that provides ten independent switch positions with a pitch of 2.54mm. Let's break down the key features of this type of DIP switch:

1. Number of Poles/Positions:

A 10-Pole DIP Switch has ten positions, allowing each switch element to be independently toggled between two states (commonly ON and OFF). Each pole represents an individual switch.

2. Pitch: The term "pitch" refers to the distance between the centers of adjacent pins. In a 2.54mm pitch DIP switch, the distance between each pin is 2.54mm. This pitch is a standard spacing commonly used in electronics.

3.Binary Configuration:

The binary nature of the switch means that each position represents a binary digit (bit), making it suitable for settings that require binary encoding. The positions can be used to represent values in binary code (0000000000 to 1111111111) depending on the switch positions.
