PCB Mount Right Angle LED Tact Switch

A PCB Mount Right Angle LED Tact Switch is designed for applications where a standard top-press tact switch does not fit the required button position.

Its side-actuated design allows users to press the switch from the edge of the PCB. This can solve a common problem in compact electronic products: there is not enough vertical space above the circuit board, or the control button needs to be placed on the side of the enclosure.

With a right-angle structure, the switch terminals are mounted to the PCB while the actuator faces horizontally. This gives engineers more flexibility when designing the front or side control interface. The button can be connected to a side panel or external mechanical structure without changing the basic PCB layout too much. For products with narrow enclosures, stacked PCBs or limited panel space, this design can make the overall assembly easier to arrange.

Basic Parameters

FVWIN right angle LED tact switches are available in compact sizes such as 6×6mm and 7×7mm. Depending on the model, the switch can feature LED illumination, momentary action and PCB mounting. LED colors can include red, green, blue and white, with selected models also available in bi-color configurations. Different actuator heights and cap options can be used to match the required button position and panel design.

The tactile action provides a clear clicking feel when the button is pressed, helping users confirm that the switch has been activated. The LED can also be used as a power, status or function indicator.

Typical Applications

This side-actuated switch is suitable for audio equipment, control panels, communication devices, test instruments, security equipment, industrial controls and other compact electronic products. It is especially useful when buttons need to be operated from the side rather than directly above the PCB.

Why Choose FVWIN?

FVWIN provides different sizes, LED colors, mounting options and button configurations to meet different PCB designs. We can also support OEM and ODM requirements when customers need customized caps, LED configurations or switch specifications. Before mass production, samples can be provided for PCB fitting and operating tests.

If your product has limited vertical space or requires a side-operated control, the PCB Mount Right Angle LED Tact Switch can provide a simple and practical solution. Contact FVWIN for samples, specifications and technical support.
