Metal Push Button Switch with Cable MS12

The 12mm Metal Push Button Switch with Cable is a compact stainless steel reset switch  for outdoor and new energy equipment.

Product Introduction

This 12mm metal push button switch is designed for equipment where panel space is limited but reliable manual control is still required. It features a stainless steel housing, raised head, reset function, and pre-connected cable, making it suitable for direct panel installation without adding a separate wiring process during assembly.

The switch has no LED and includes a power symbol on the button surface for easy identification. Its IP67-rated construction helps protect the switch against dust and temporary water immersion, making it suitable for outdoor equipment and control panels exposed to moisture or changing weather conditions.

With its small 12mm cut-out size, the switch can be integrated into compact control panels while maintaining a simple and clean appearance.

Product Specifications

Product Features and Selling Points

1. Compact 12mm Cut-Out

The 12mm cut-out is useful for equipment with limited panel space. Compared with larger metal push buttons, this compact format allows engineers to reserve more space for other controls, displays, and connectors.

2. Stainless Steel Housing

The stainless steel construction provides a solid external structure and is suitable for equipment that requires a metal switch surface. It also works well with modern industrial equipment where a simple and clean panel appearance is preferred.

3. IP67 Protection

The IP67 rating makes this switch suitable for applications where protection against dust and water is required. This is particularly useful for outdoor equipment that may be exposed to rain, humidity, and changing environmental conditions.

4. Raised Head with Power Symbol

The raised button design provides a clear operating surface, while the power symbol makes the switch function easier to identify on the panel. This can be useful for equipment with several buttons or controls.

The switch does not include an LED, making it suitable for applications where visual lighting is not required.

5. Pre-Wired Design

The switch is supplied with a cable connection, reducing the need for additional wiring work during panel assembly. For equipment manufacturers, this can make installation more straightforward, especially when the switch is installed in a compact control box.

Cable length and other wiring requirements should be confirmed according to the selected model.

6. Reset Function

The reset function is suitable for control systems where the button needs to provide a manual reset operation. It can be used for equipment reset, control input, or other defined switching functions depending on the circuit design.

Applications

This 12mm Cut-out Metal Push Button Switch with Cable is particularly suitable for new energy and outdoor equipment, including:

EV charging stations, Solar PV inverters, Wind power control systems, Smart irrigation controllers, Outdoor control equipment, New energy equipment, Compact industrial control boxes, Outdoor electrical equipment

For these applications, switch selection usually involves more than checking the mounting size. Engineers should consider water and dust protection, installation space, operating function, cable connection, environmental conditions, and the electrical requirements of the control circuit.

About FVWIN

FVWIN is a manufacturer of electronic switches and connectors, supplying metal push button switches, illuminated tact switches, DIP switches, DC power jacks, and other electronic components.

For different equipment designs, FVWIN can provide various switch sizes, head styles, operating functions, LED configurations, wiring options, and other specifications. OEM and ODM support is also available for customers with specific mechanical or electrical requirements.

Samples and product specifications can be provided for engineering evaluation before volume production.

FAQ

Q1: What is the cut-out size of this metal push button switch?
A: The switch is designed for a 12mm panel cut-out. Please check the product drawing for the exact mounting dimensions and panel thickness requirements.

Q2: Does this switch have an LED?
A: No. This version is a non-illuminated metal push button switch with a power symbol.

Q3: What is the function of the switch?
A: This model uses a reset function, suitable for manual reset or control input applications.
